Features
|
Advantages
|
|
Rapid curing
|
Through ultraviolet irradiation to achieve rapid curing, curing time is usually between a few tenths of a second to a few seconds, greatly improving production efficiency
|
|
Wear and scratch resistance
|
It can effectively protect the surface of printed matter and extend the service life
|
|
Environmental protection
|
No volatile solvent, no harmful substances emitted during the curing process
|
1. Viscosity / Fluidity / Curing Speed Specification Table
| Item |
Parameter |
Remarks |
| Viscosity(25℃, falling‑rod viscometer) |
35‑60 Pa·s |
Suitable for sheet‑fed offset press; shear‑thinning behavior during printing |
| Ink Tack (32℃,400rpm) |
10‑14 |
Balanced transfer performance, low misting risk |
| Flow value |
26‑30 mm |
Good leveling, no pin‑hole on printed surface |
| Curing energy requirement |
90‑140 mJ/cm² |
Mercury‑vapor UV lamp, 365‑405 nm; support partial LED‑UV source |
| Curing speed |
0.2‑2 seconds |
Depends on lamp power & printing speed; instant cure under full UV irradiation |
| Film property after cure |
High hardness, scratch‑resistant, release effect |
Anti-forgey OP vanish & release varnish function |
| Feature |
Zero‑VOC, no volatile solvent during curing |
Environment‑friendly formulation |
Note: Actual performance will be influenced by lamp aging, printing speed, ink film thickness and substrate surface tension.
2. Compatible Printing Process & Substrate Compatibility List
Compatible Printing Methods Quick‑lookup
表格
| Printing Method |
Compatibility |
Remarks |
| Sheet‑fed Offset Printing |
✅ Recommended |
Main application for release / OP vanish |
| Web Offset Printing |
✅ Conditional |
Need adjust ink tack & press parameters |
| Flexographic Printing |
❌ Not recommended |
Different viscosity requirement |
| Gravure Printing |
❌ Not recommended |
Not formulated for gravure anilox |
Substrate Compatibility
表格
| Substrate Type |
Compatibility |
Remarks |
| Coated art paper, cardboard, silver/gold card |
✅ Excellent |
Packaging box, gift box, carton |
| Treated‑PET / PVC film |
✅ Good |
Substrate surface tension ≥38 dyne/cm required |
| BOPP / PP plastic film |
⚠️ Conditional |
Must do corona / surface pretreatment |
| Metal coated sheet / aluminum foil paper |
✅ Good |
For metal‑packaging anti‑forgery overprint |
| Untreated PE / PP |
❌ Poor adhesion |
Not suggested without primer coating |
3. 1‑kg Series Packaging Selection Guide, Storage & Shelf‑life
1‑kg Packaging Options Guide
表格
| Packing Type |
Description |
Best‑for Scenario |
| Standard 1kg sealed iron can |
Default factory package, light‑proof airtight metal can |
General bulk order, long‑term stock |
| 1kg iron can with custom label |
OEM private label sticker on original can |
Reseller / brand‑customer requirement |
| Custom carton outer‑box |
Outer carton marked with customer logo, inner 1kg cans |
Full‑custom export order |
MOQ for OEM custom label: 50 kg; plain stock goods use standard CERES‑branded 1kg iron cans.
Storage Condition & Shelf‑life
| Item |
Specification |
| Storage Temperature |
15‑25 ℃; strictly avoid >30 ℃ high temperature; keep away from UV‑light / sunshine |
| Relative Humidity |
40‑65 % RH; keep warehouse dry & ventilated, far from fire source |
| Light‑proof requirement |
Must keep iron‑can tightly sealed. Avoid direct sunlight & UV‑radiation. Once opened, seal lid tightly after each use. |
| Shelf‑life |
12 months under unopened & standard storage condition |
| Opened‑can usage suggestion |
Finish within 3‑4 months after opening; sedimentation may occur if stored too long. |
Important Reminder: If ink appears thickening, gelling or obvious sediment before expiration date, it indicates improper storage and should stop using.
4. FAQ Frequently Asked Questions
Q1: What is MOQ? A: Minimum order quantity is 1 kg for sample testing. Bulk order starts from 25 kg. Small‑batch sample is available for customer press test.
Q2: What is delivery lead‑time? A: Stock items: ship within 2‑3 working days after receiving payment. Custom formula / OEM private‑label goods: 12‑15 working days.
Q3: What customization can you provide? A: Support custom release‑effect grade, custom hardness / scratch‑resistance performance, OEM private‑label sticker & custom carton packaging. We can adjust formula for special antif-orgeryprinting requirement.
Q4: Logistics & shipping options for UV ink? A: Ink belongs to chemical liquid goods. Express: FedEx is primary option for international shipment (transit time 3‑4 working days). Sea‑freight / air‑freight for large bulk order. Payment terms: T/T.
Q5: Why cured vanish surface still sticky? A: Check these points: UV lamp power & aging status; printing speed too fast; insufficient curing energy; ink film too thick. Increase UV energy or reduce press speed accordingly.
Q6: Bad adhesion on plastic film? A: Confirm substrate surface tension ≥38 dyne/cm. Plastic films need corona‑treatment before printing; add matching primer if necessary.
Q7: Can I mix this ink with other brand UV ink? A: Not recommended. Different resin systems may cause gelling, sediment or unstable curing. Test small sample first if mixing is unavoidable.
5. Competitive Product Comparison Table
| Comparison Item |
CERES UV Offset Release / OP Vanish |
General domestic ordinary UV offset vanish |
Imported premium UV offset vanish |
| Main function |
Rapid cure, wear‑scratch resistant, release‑effect & anti‑forgery OP vanish |
Basic UV overprint vanish, no special release property |
High‑grade vanish, partial with release function |
| Viscosity & tack |
35‑60 Pa·s, tack 10‑14; good transfer, low misting |
Viscosity range unstable, easy misting at high‑speed press |
Stable viscosity & tack, wide process window |
| Curing energy demand |
90‑140 mJ/cm², compatible with mercury lamp & partial LED‑UV |
Need higher curing energy ≥150 mJ/cm² |
80‑120 mJ/cm², low energy consumption |
| Abrasion‑scratch resistance |
Excellent, good for packaging anti‑forgery protection |
Normal scratch resistance, easy scratch under heavy friction |
Superior scratch‑resistance performance |
| Release‑effect feature |
Adjustable release strength for anti‑forgery application |
No release function |
Adjustable release, high price |
| VOC performance |
Zero‑VOC, environment‑friendly |
Minor residual volatile substance |
Zero‑VOC compliance |
| Price level |
Cost‑effective middle‑range |
Low‑cost entry level |
High premium price |
| Core advantages |
Integrated release‑effect + anti‑forgery OP vanish performance; good balance of curing speed & wear resistance; competitive price for export‑oriented packaging printer |
Low purchase cost, only basic overprint protection |
Top‑tier performance, expensive procurement cost |
Core selling point:Combines fast curing, scratch‑resistance and adjustable release function, specially optimized for anti‑forgery packaging offset printing; zero‑VOC eco‑friendly formula, perfect for export‑packaging customers.
6. Customer Cases & Testimonials
- South‑East Asia packaging printing factory Used for anti‑forgery OP vanish on gift‑box & cosmetic carton. Fast UV curing, stable release‑effect, effectively protects printed surface, replaced high‑cost imported vanish to cut comprehensive cost.
- Middle‑East label & anti‑forgeryprinting house Applied on silver‑card packaging sheet. Good scratch‑resistance after UV curing, stable performance under high‑speed sheet‑fed offset production.
- South‑America small‑mid packaging converter Suitable for multi‑variety small‑batch anti‑forgery jobs. Wide curing‑energy tolerance, works well with existing standard UV offset equipment.
Customer real‑feedback quote: “This CERES UV offset vanish brings us reliable release‑effect for anti‑forgery packaging. Fast curing speed improves our press throughput, scratch‑resistance meets our packaging requirement. Good value for money.”
Basic Original‑page Product Information
‑ Place of Origin: Guangdong, China ‑ Brand Name: CERES ‑ Printing Type: Offset Printing ‑ Type: UV Ink / UV Release & OP Vanish ‑ MOQ: 1 kg ‑ Unit Price: USD 5.50 / kilogram ‑ Payment Term: T/T ‑ Shipping Options: DHL, UPS, TNT, FEDEX, EMS
