Place of Origin:
Japan
Brand Name:
FUJIFILM
Model Number:
SDU-201
Details:
1. Printing method
Offset printing method, it is possible to letterpress printing method both.
2. Print the order
Spot printing please perform last.
3. Plate material
I recommend for the long run of offset printing ... negative type (our FND, FNL) or UV printing for positive type (the Company VZ).
Toppan Printing ... we recommend the butyl rubber.
4. Print speed
100m / min before and after is adequate.
5.UV irradiation lamp
6 ~ 8KW is appropriate, but please pay attention to the life of the UV lamp.
6. Confirmation of color density
Please check by writing spray checker Oyopi ballpoint pen.
Number of copies, please to guide the three copying.
7. Paper
Above paper (A paper), please use spot printing for the (S-type).
8. Cleaning
Cleaning solution, please use the UV ink dedicated cleaning solution.
9. Note
You can seal in such ink pad or name sign on top of the UV spot printing, that you put a such as revenue stamp Please avoid.
Fujifilm Because it is ink that is quality design on a dedicated, and when it is used in carbonless paper other than , if it is the wrong use, quality guarantee.
10. Storage of ink
Inks, please keep at room temperature (25 ℃) the following locations
Method of use:
1 sdus - 201 is offset printing, letterpress printing UV ink type of intensifying combination. 2 first printing lines and text, intensifying printing in the final, please.
3Please use the type A paper.
4 PS version please use the resistance type seal type long life. Please use a ball-point pen to write
5 hair color concentration.
6 printing after cleaning, please use UV special cleaning fluid. 7 intensifying ink under 25 ° environment preservation.
