Printing Germany Lohmann Film Carrier Tape 0.20 Lohmann Tape
Founded in 1851, Lohmann is one of the pioneering forces in adhesive tape technology and is
now active on a global scale. The Adhesive Tape Group is headquartered in Neuwied, Germany.
The company now has over 1,500 employees worldwide and exclusive
sales partners in over 50 countries all around the world.
Features:
- Excellent tolerance compliance
- Mounting of photo-polymer plates on printing cylinders
- PVC film with filmic carrier and rubber pressure-sensitive adhesive
Advantage:
Excellent tolerance compliance
Mounting of photo-polymer plates on printing cylinders
PVC film pressure-sensitive adhesive
Properties:
| |
Name |
Color |
Thickness (mm) |
| Liner |
Creped PVC film |
green |
approx. 0.70 |
| Adhesive closed side |
Rubber |
|
|
| Carrier |
PVC film |
green-transparent |
approx. 0.20 |
| Adhesive open side |
Rubber |
|
|
| |
|
Total thickness: |
approx. 0.90 |
The thickness is 0.1mm, if you are looking for thickness 0.1mm, please let me know. thanks.
Packaging:Rolls: 310mm×4.5m (width×length)
Specification & Tack‑Grade
表格
| Item |
Value |
| Model |
DuploFLEX FOL 0.20 |
| PVC carrier thickness |
0.20 mm |
| Total tape thickness |
0.90 mm |
| Liner |
Creped green PVC liner 0.70 mm |
| Standard size |
310 mm ×4.5 m per roll |
| Alternative stock grade |
FOL 0.10 (0.10 mm carrier) |
| Temperature range |
‑20℃ ~ +85℃ |
| Adhesive grade |
Grade‑MH Medium‑High tack(plate‑side higher than roller‑side) |
Tack‑grade reference: ‑ Grade‑L: Low‑tack for frequent plate‑change ‑ Grade‑M: Medium‑tack general flexo plate ‑ Grade‑MH: Medium‑High‑tack (this item) for high‑speed rotary press ‑ Grade‑H: High‑tack for heavy thick plate, higher residue risk on demounting
Substrate Bonding Performance
| Substrate |
Bonding result |
Remarks |
| Metal chrome‑plated printing roller |
✅ Excellent |
Clean demounting with little residue |
| Photopolymer flexo plate |
✅ Excellent |
Core application, anti‑shift under high‑speed printing |
| PVC / PET plastic sheet |
△ Good |
Surface must be oil‑free |
| Paper / cardboard |
△ Fair |
Not for long‑term paper bonding |
| Fabric textile |
× Not recommended |
Heavy adhesive residue after removal |
Pre‑treatment: Clean oil & dust from roller surface before mounting tape.
Original Factory Document Info
‑ Authorized distributor certificate available upon business request. ‑ Original TDS data‑sheet & RoHS compliance report for export customer audit. ‑ Genuine goods carry printed Lohmann / DuploFLEX FOL0.20 marking on core and carton box.
FAQ
- MOQ: 2 rolls for stock; 1‑roll sample available, freight collect.
- Lead‑time: 3 working‑days for stock; 7‑12 working‑days for custom slitting width.
- Customization: FOL0.10 alternative grade available; custom slitting width 80‑310 mm. Carrier thickness cannot be modified.
- Shipping: DHL/TNT/UPS, air & sea freight; non‑hazardous industrial adhesive tape.
- Plate‑shifting trouble: Clean oil/dust on roller; check working temperature not exceed 85℃; make sure release liner is fully peeled off.
- Adhesive residue: Genuine Lohmann leaves minimal residue; heavy residue may be fake goods or over‑temperature running. Do NOT reuse tape repeatedly.
- Grade selection: FOL0.10 for thin plate & fine screen dot; FOL0.20 for thick plate & high‑speed rotary press.
- Storage: Store 15‑25℃ cool dry dark place, store rolls vertically, avoid heavy compression. Un‑opened shelf‑life:12 months.
Competitor Comparison
| Item |
Original Lohmann DuploFLEX FOL0.20 |
Generic domestic imitation tape |
Other imported mounting tape |
| PVC carrier |
Germany‑origin PVC, low thermal elongation |
Domestic ordinary PVC, easy stretch under heat |
Import high‑quality film carrier |
| Double‑sided differential tack |
Plate‑side higher tack, roller‑side medium tack for low‑residue demounting |
Similar tack on both‑sides, heavy residue after demounting |
Differential‑tack design |
| Temperature resistance |
‑20~+85℃, anti‑plate‑shift for rotary press |
Risk of plate‑shift above 60℃ |
Good temperature‑resistant performance |
| Residue after demounting |
Minimal residue, reduce roller‑cleaning downtime |
Heavy adhesive residue, solvent cleaning required |
Low‑residue property |
| Document support |
Distributor authorization, TDS, RoHS report available |
Lack complete original technical documents |
Full compliance documents |
| Stock availability |
310mm×4.5m in stock |
Unstable stock supply |
Long import lead‑time |
Customer Cases & Testimonials
‑ Case 1: Domestic label flexo printing plant, DuploFLEX FOL0.20 for photopolymer plate mounting on rotary flexo press, monthly purchase 30‑50 rolls, less downtime caused by plate‑shift & adhesive residue. ‑ Case 2: Southeast‑Asia packaging printing factory, original Lohmann tape with full set of compliance documents for export production, repeat bulk‑orders.
“Differential double‑sided tack, minimal adhesive residue after plate demounting, good dimensional stability under high‑speed flexo‑press.” “Original Lohmann product, complete TDS & RoHS documents convenient for export order audit.”
